Toys: Electric Marker Series

GP Model	Cell Size	Nominal Voltage (V)	Capacity (0.2C discharge)		Nominal Dimension		Wt (g)	Standard Charge		1 Hr Charge Current (mA)
			Minimum (mAh)	Typical (mAh)	Dia (mm)	Ht (mm)		Current (mA)	Time (hr)
GP110AFHR	2/3 AF	1.2	1045	1100	21.5	28.5	21.5	110	16	1100
GP200AFHR	4/5 AF	1.2	1900	2000	35.5	43	35.5	200	16	2000
GP130LAHR	-	1.2	1235	1300	25	27.5	25	130	16	1300
GP130SCHR	2/3 Sub-C	1.2	1235	1300	32	27.5	32	130	16	1300
GP220SCHR	4/5 Sub-C	1.2	2090	2200	44	34	44	220	16	2200
GP300SCHR	Sub-C	1.2	2800	3000	61	43	61	300	16	3000
GP330SCHR*	Sub-C	1.2	3100	3300	62	43	62	330	16	3300
GP370SCHR*	Sub-C	1.2	3400	3700	64.5	43	64.5	360	16	3600
GP430SCHR	Sub-C	1.2	4100	4100	66	43	66	410	16	4100

*Models with UL approval



Toys: Mini Car Series

GP Model	Cell Size	Nominal Voltage (V)	Capacity (0.2C discharge)		Nominal Dimension		Wt (g)	Standard Charge		1 Hr Charge Current (mA)
			Minimum (mAh)	Typical (mAh)	Dia (mm)	Ht (mm)		Current (mA)	Time (hr)
GP11AAAM	1/4 AAA	1.2	110	115	2.8	10.7	2.8	11	16	110
GP10AAAHR	1/3 AAA	1.2	100	110	3.9	15.6	3.9	10	16	100
GP12AAAHR	1/3 AAA	1.2	120	130	4.4	17.7	4.4	12	16	120
GP16AAAM*	1/3 AAA	1.2	160	168	3.75	14.7	3.75	16	16	160
GP25AAAHR	1/2 AAA	1.2	250	260	6.3	23.5	6.3	25	16	250
GP110AFHR	2/3 AF	1.2	1045	1100	21.5	28.5	21.5	110	16	1100

*Models with UL approval



Toys: Pro Racing Cars & Boats Series

GP Model	Cell Size	Nominal Voltage (V)	Capacity (0.2C discharge)		Nominal Dimension		Wt (g)	Standard Charge		1 Hr Charge Current (mA)
			Minimum (mAh)	Typical (mAh)	Dia (mm)	Ht (mm)		Current (mA)	Time (hr)
GP300SCHR	Sub-C	1.2	2800	3000	61	43	61	300	16	3000
GP330SCHR*	Sub-C	1.2	3100	3300	62	43	62	330	16	3300
GP370SCHR*	Sub-C	1.2	3400	3700	64.5	43	64.5	360	16	3600
GP430SCHR	Sub-C	1.2	4100	4100	66	43	66	410	16	4100

*Models with UL approval



Toys: RC Plane Series

GP Model	Cell Size	Nominal Voltage (V)	Capacity (0.2C discharge)		Nominal Dimension		Wt (g)	Standard Charge		1 Hr Charge Current (mA)
			Minimum (mAh)	Typical (mAh)	Dia (mm)	Ht (mm)		Current (mA)	Time (hr)
GP30AAAAH	AAAA	1.2	300	320	6.5	40.6	6.5	30	16	300
GP10AAAHR	1/3 AAA	1.2	100	110	3.9	15.6	3.9	10	16	100
GP12AAAHR	1/3 AAA	1.2	120	130	4.4	17.7	4.4	12	16	120
GP25AAAHR	1/2 AAA	1.2	250	260	6.3	23.5	6.3	25	16	250
GP110AFHR	2/3 AF	1.2	1045	1100	21.5	28.5	21.5	110	16	1100
GP200AFHR	4/5 AF	1.2	1900	2000	35.5	43	35.5	200	16	2000
GP130LAHR	-	1.2	1235	1300	25	27.5	25	130	16	1300
GP130SCHR	2/3 Sub-C	1.2	1235	1300	32	27.5	32	130	16	1300
GP220SCHR	4/5 Sub-C	1.2	2090	2200	44	34	44	220	16	2200
GP300SCHR	Sub-C	1.2	2800	3000	61	43	61	300	16	3000
GP330SCHR*	Sub-C	1.2	3100	3300	62	43	62	330	16	3300
GP370SCHR*	Sub-C	1.2	3400	3700	64.5	43	64.5	360	16	3600
GP430SCHR	Sub-C	1.2	4100	4100	66	43	66	410	16	4100

*Models with UL approval



Toys: RC Car Series

GP Model	Cell Size	Nominal Voltage (V)	Capacity (0.2C discharge)		Nominal Dimension		Wt (g)	Standard Charge		1 Hr Charge Current (mA)
			Minimum (mAh)	Typical (mAh)	Dia (mm)	Ht (mm)		Current (mA)	Time (hr)
GP100AAS*	AA	1.2	1000	1030	26.5	48.2	26.5	100	16	1000
GP130AAM*	AA	1.2	1300	1340	25	48.2	25	130	16	1300
GP150AAM*	AA	1.2	1500	1530	26	48.2	26	150	16	1500
GP160AAH*	AA	1.2	1600	1640	26	49.2	26	160	16	1600
GP170AAH	AA	1.2	1700	1750	27	49.2	27	170	16	1700
GP180AAH	AA	1.2	1800	1850	27	49.2	27	180	16	1800
GP60AAS*	AA	1.2	600	660	18	48.2	18	60	16	600
GP70AAS*	AA	1.2	700	770	21	48.2	21	70	16	700
GP80AAS*	AA	1.2	800	850	21	48.2	21	80	16	800
GP130SCK	Sub-C	1.2	1300	1430	41	43	41	130	16	1300
GP140SCH	Sub-C	1.2	1400	1470	40	43	40	140	16	1400
GP160SCK*	Sub-C	1.2	1600	1760	46	43	46	160	16	1600
GP200SCK*	Sub-C	1.2	2000	2200	53	43	53	200	16	2000
GP220SCH*	Sub-C	1.2	2200	2420	55	43	55	220	16	2200
GP300SCH	Sub-C	1.2	3000	3150	61	43	61	300	16	3000
GP390SCH	Sub-C	1.2	3800	3900	63	43	63	380	16	3800

*Models with UL approval
