NiMH: Button High Capacity Series
GP Model Nominal
Voltage
(V)		 End
Voltage
(V)		 Nominal
Capacity
at 5-hr
Rate
(mAh)		 Nominal
Dimension		 Wt
(g)		 Standard Charge
Dia
(mm) 		Ht
(mm) 		Current
(mA) 		Time
(hr) 		Max
Charging
Voltage
(V)
GP150BVH 1.2 1.0 120 15.5 7.8 4.8 12 16 1.5
GP15BNH* 1.2 1.0 15 9.5 2.6 0.7 1.5 16 1.5
GP170BVH 1.2 1.0 170 25 6.4 9.8 17 16 1.5
GP2BNH 1.2 1.0 2 6.7 1.5 0.31 0.2 16 1.5
GP20BNH* 1.2 1.0 20 11.5 2.25 1 2 16 1.5
GP25BNH 1.2 1.0 25 11.6 3.5 1.4 2.5 16 1.5
GP250BVH 1.2 1.0 250 25 6.4 10.9 25 16 1.5
GP280BVH 1.2 1.0 280 25 8.7 12.6 28 16 1.5
GP320BVH 1.2 1.0 320 25 8.7 14.1 32 16 1.5
GP40BVH* 1.2 1.0 40 11.6 5.5 1.9 4 16 1.5
GP60BVH 1.2 1.0 60 15.5 6.3 3.6 6 16 1.5
GP80BVH* 1.2 1.0 80 15.5 6.3 3.7 8 16 1.5
*Models with UL approval



GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh) 		Typical
(mAh) 		Dia
(mm) 		Ht
(mm) 		Current
(mA) 		Time
(hr)
GP17R7H* 9V 7.2 170 175 15.7(T) x 26.5(W) x 48.5(H) 28 17 16 170
GP17R8H* 9V 8.4 170 175 15.7(T) x 26.5(W) x 48.5(H) 32 17 16 170
GP17R9H* 9V 9.6 170 175 15.7(T) x 26.5(W) x 48.5(H) 36 17 16 170
GP20R7H 9V 7.2 200 210 15.7(T) x 26.5(W) x 48.5(H) 36.5 20 16 200
GP20R8H 9V 8.4 200 210 15.7(T) x 26.5(W) x 48.5(H) 42.5 20 16 200
GP30R7H 9V 7.2 300 320 17.5(T) x 26.2(W) x 48.5(H) 48.5 30 16 300
*Models with UL approval



NiMH: High Capacity Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh) 		Typical
(mAh) 		Dia
(mm) 		Ht
(mm) 		Current
(mA) 		Time
(hr)
GP40AAAM 2/3 AAA 1.2 400 428 10.2 29.2 7.7 40 16 400
GP50AAASH 4/5 AAA 1.2 500 515 10.4 36.3 9.3 50 16 500
GP65AAAH AAA 1.2 650 680 10.5 43.7 13 65 16 650
GP70AAAH* AAA 1.2 700 730 10.5 43.7 13 70 16 700
GP75AAAH* AAA 1.2 750 780 10.5 43.7 13 75 16 750
GP80AAAH AAA 1.2 780 800 10.5 43.7 14 80 16 800
GP85AAALH AAAL 1.2 850 880 10.5 50 15 85 16 850
GP91AAALH AAAL 1.2 910 930 10.5 50 15.1 91 16 910
GP100AAALH 7/5 AAAL 1.2 1000 1050 10.5 66.5 19.5 100 16 1000
GP120AAALH 9/5 AAAL 1.2 1200 1250 10.5 80 23 120 16 1200
GP75AAH 2/3 AA 1.2 750 770 14.5 28.7 15 75 16 750
GP150AAM* AA 1.2 1500 1530 14.4 48.2 26 150 16 1500
GP160AAH* AA 1.2 1600 1640 14.5 49.2 26 160 16 1600
GP170AAH AA 1.2 1700 1750 14.5 49.2 27 170 16 1700
GP180AAH AA 1.2 1800 1850 14.5 49.2 27 180 16 1800
GP200AAH* AA 1.2 2000 2050 14.5 49.5 28.8 200 16 2000
GP210AAH AA 1.2 2100 2150 14.5 49.5 29.5 210 16 2100
GP220AAH AA 1.2 2200 2250 14.5 49.5 30.5 220 16 2200
GP190AAH 7/5 AA 1.2 1900 1960 14.5 65 35 190 16 1900
GP211AFH* 4/5 AF 1.2 2100 2160 17 43 32 210 16 2100
GP250AFH* AF 1.2 2500 2550 17 50.2 39 250 16 2500
GP270AFH AF 1.2 2600 2700 17 50.2 39.5 270 16 2700
GP370AFM 7/5 AF 1.2 3700 3750 17.2 67 52 370 16 3700
GP380AFH* 7/5 AF 1.2 3700 3800 17.5 67 53.5 380 16 3800
GP50NH N 1.2 500 520 11.65 29.4 9.8 50 16 500
GP410LAH 18650 1.2 4100 4220 18.3 65.5 58 410 16 4100
GP450LAH* 18670 1.2 4300 4500 18.3 67 60 450 16 4500
GP200SCH 4/5 Sub-C 1.2 2000 2100 23 34 48 200 16 2000
GP330SCH Sub-C 1.2 3100 3300 23 44.5 62 330 16 3300
GP350CH C 1.2 3500 3850 25.8 50 78.5 350 16 3500
GP400CH C 1.2 4000 4200 25.8 50 82 400 16 4000
GP700DH* D 1.2 7000 7350 33 60 155 700 16 7000
GP900DH* D 1.2 9000 9225 33 60 170 900 16 Not Applicable
GP1300FH F 1.2 13000 13650 33 90 247 1300 16 Not Applicable
*Models with UL approval

NiMH: High Temperature Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh) 		Typical
(mAh) 		Dia
(mm) 		Ht
(mm) 		Current
(mA) 		Time
(hr)
GP60AAAHT AAA 1.2 600 630 10.5 43.7 13 60 16 Not Applicable
GP110AAHT AA 1.2 1100 1155 14.4 48.2 21.5 110 16 Not Applicable
GP125AAMT* AA 1.2 1250 1280 14.4 48.2 26 125 16 Not Applicable
GP160AFHT 4/5 AF 1.2 1600 1680 17 43 33 160 16 Not Applicable
GP210AFHT AF 1.2 2100 2205 17 50 38 210 16 Not Applicable
GP400LAHT 18700 1.2 4000 4200 18.3 70 66 400 16 Not Applicable
GP220SCHT* Sub-C 1.2 2200 2420 23 43 53 220 16 Not Applicable
GP220SCHTD Sub-C 1.2 2200 2420 23 42 53.5 220 16 Not Applicable
*Models with UL approval



NiMH: Prismatic Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh) 		Typical
(mAh) 		Dia
(mm) 		Ht
(mm) 		Current
(mA) 		Time
(hr)
GP14M* Prismatic 1.2 1250 1400 6.1(T) x 17.0(W) x 67.0(H) 23 125 16 1250
GP14M145* Prismatic 1.2 1350 1450 6.1(T) x 17.0(W) x 67.0(H) 25 135 16 1350
GP2M Prismatic 1.2 220 250 6.1(T) x 17.0(W) x 20.0(H) 6 22 16 220
GP4M Prismatic 1.2 400 440 6.1(T) x 17.0(W) x 31.3(H) 10 40 16 400
GP5M Prismatic 1.2 500 550 6.1(T) x 17.0(W) x 35.3(H) 12 50 16 500
GP5M60 Prismatic 1.2 550 600 6.1(T) x 17.0(W) x 35.3(H) 11 55 16 550
GPF6M Prismatic 1.2 550 600 6.7(T) x 16.1(W) x 33.8(H) 11 55 16 550
GP5M70 Prismatic 1.2 640 700 6.1(T) x 17.0(W) x 36.0(H) 12 64 16 640
GP7MS Prismatic 1.2 700 750 6.1(T) x 17.0(W) x 67.0(H) 17 70 16 700
GP7H Prismatic 1.2 720 780 8.3(T) x 17.0(W) x 35.3(H) 15 72 16 720
GP8M Prismatic 1.2 800 850 6.1(T) x 17.0(W) x 48.0(H) 17 80 16 800
GP14M95 Prismatic 1.2 900 950 6.1(T) x 17.0(W) x 67.0(H) 21 90 16 900
*Models with UL approval



NiMH: Standard Series
GP Model Cell
Size		 Nominal
Voltage
(V)		 Capacity
(0.2C discharge)		 Nominal
Dimension		 Wt
(g)		 Standard
Charge		 1 Hr
Charge
Current
(mA)
Minimum
(mAh) 		Typical
(mAh) 		Dia
(mm) 		Ht
(mm) 		Current
(mA) 		Time
(hr)
GP10AAAAH 1/3 AAAA 1.2 100 105 8.6 15.4 2.6 10 16 100
GP15AAAAH 1/2 AAAA 1.2 150 168 8.6 20.5 3.5 15 16 150
GP18AAAAH 1/2 AAAA 1.2 180 185 8.6 20.5 4 18 16 180
GP20AAAAH 2/3 AAAA 1.2 200 210 8.6 29.5 4.7 20 16 200
GP30AAAAH AAAA 1.2 300 320 8.4 40.6 6.5 30 16 300
GP50AAAAH 7/5 AAAA 1.2 500 520 8.4 66 10.5 50 16 500
GP11AAAM 1/4 AAA 1.2 110 115 10.2 10.7 2.8 11 16 110
GP10AAAHR 1/3 AAA 1.2 100 110 10.4 15.6 3.9 10 16 100
GP16AAAM* 1/3 AAA 1.2 160 168 10.2 14.6 3.75 16 16 160
GP25AAAHR 1/3 AAA 1.2 250 260 10.5 23.5 6.3 25 16 250
GP33AAAH 1/2 AAA 1.2 315 330 10.4 22.4 6 33 16 330
GP30AAAM* 2/3 AAA 1.2 300 315 10.2 29.2 7.2 30 16 300
GP40AAAH 4/5 AAA 1.2 400 450 10.4 36.3 8.5 40 16 400
GP55AAAH* AAA 1.2 550 578 10.5 43.7 13 55 16 550
GP60AAAH* AAA 1.2 600 630 10.5 43.7 13 60 16 600
GP25AAH 1/3 AA 1.2 250 270 14.5 16.6 7 25 16 250
GP30AAH 2/3 AA 1.2 300 320 14.5 28.7 10 30 16 300
GP135AAH 4/5 AA 1.2 1350 1400 14.5 42.5 22.8 135 16 1350
GP60AAM AA 1.2 600 630 14.4 48.2 15 60 16 600
GP130AAM* AA 1.2 1300 1340 14.4 48.2 25 130 16 1300
GP45AFH 1/3 AF 1.2 450 500 17 16.3 10 45 16 450
GP60AFH 1/2 AF 1.2 600 650 17 22 14 60 16 600
GP100AFH 2/3 AF 1.2 1000 1080 17 28.7 22 100 16 1000
GP110AFH 2/3 AF 1.2 1100 1133 17 28.5 21 110 16 1100
GP181AFH 4/5 AF 1.2 1800 1860 17 43 32 180 16 1800
GP230AFH AF 1.2 2300 2350 17 50.2 36 230 16 2300
GP13NH 1/3 N 1.2 130 137 11.65 12.4 3.85 13 16 130
GP23NH 1/2 N 1.2 230 241 11.65 17 6.2 23 16 230
GP36NH N 1.2 360 380 11.65 29.4 8.6 36 16 360
GP80LAH 18210 1.2 800 860 18.3 21.5 17 80 16 800
GP170SCH 4/5 Sub-C 1.2 1700 1870 23 34 46 170 16 1700
GP140SCH Sub-C 1.2 1400 1470 23 43 40 140 16 1400
GP220SCH* Sub-C 1.2 2200 2420 23 43 55 220 16 2200
GP300SCHE Sub-C 1.2 3000 3150 23 43 59 300 16 3000
GP450DH D 1.2 4500 4725 33 60 130 450 16 Not Applicable
*Models with UL approval
